App-based device management
The mobile app supports device discovery, network configuration, real-time preview, venue calibration, live streaming, recording, scoring and event-video management.
VAKTAR AI 180 · AI Sports Vision Systems
VAKTAR AI 180 — an AI sports camera for game intelligence in real time.
VAKTAR AI 180 is Apollo NZ Global’s AI sports-vision pathway for clubs, schools, courts, fields and events that need wide fixed-position capture, local recording, live streaming and app-based venue control without a conventional camera crew. The current camera platform supports sport-specific calibration, scoring, highlight capture and video management across a repeatable venue workflow.
Start Smart Quote Ask Apollo AIView My ProjectBrowse all systemsCurrent Camera Setup GuideCurrent App User Manual
180° panoramic dual-lens viewRecording + live streamingSport calibration + scoring + highlights
VAKTAR branding lives in the platform and website identity; supplied camera hardware is shown without exterior brand marks.Technical overview
VAKTAR AI 180 hardware, app and operating specification
The current camera and app material covers the hardware, connection workflow, venue positioning, live and recording rules, calibration and match-management tools. Exact supplied model and configuration are confirmed at quotation.
01Current camera models
WA100-PRO / WA100-AIRThe VAKTAR customer-facing brand sits over the current sports-camera hardware pathway. Exact model is confirmed for each project.
02Image sensor
1/1.8″ 4K CMOSProgressive-scan sensor; 2.8 mm fixed-focus lens; F1.2.
03Field of view
180° H / 59° VDual-lens panoramic stitched output up to 16 MP.
04Panorama quality modes
SD / HD / Ultra HDThe current app manual lists 1920×1080 at 4096 Kbps for SD, 1920×1080 at 8192 Kbps for HD and 2560×1440 at 8192 Kbps for Ultra HD.
05Current recording / live pathway
4K recording + 1080P liveCurrent product information retains this pathway; the app manual separately lists selectable panoramic quality modes.
06Storage
64 GB eMMCMicroSD support is also documented.
07Connectivity
Wi-Fi 6 + RJ45 + Bluetooth 5.210/100M Ethernet and USB-C are documented; 4G use is also supported where the configured model/SIM pathway applies.
08App connection
Bluetooth + Wi-Fi discoveryEnable Bluetooth and Wi-Fi, search for the device by serial number, connect, preview the camera and complete venue calibration before use.
09App guide
Android 10.0+ documentedThe supplied manual also documents account login by email/mobile and an offline guest-control mode for emergency use.
10Live-stream network
Wired / Wi-Fi / 4GExternal network access is required for live streaming; local recording does not require the external network.
11Battery
Up to 10 hours11.1 V 8000 mAh / 88.8 Wh; ≤15 W.
12Battery safeguards
<10% alert / <5% auto-stopStreaming or recording can continue after the low-battery alert, then stops automatically below 5%.
13Storage safeguards
<5 GB alert / <2 GB auto-stopThese thresholds are documented for streaming and recording.
14Basketball setup
Approx. 2.2–5 m height pathwayThe current guide pairs 1–4 m horizontal setback with progressively higher mounting ranges; final placement should be tested against the actual court view.
15Football setup
Approx. 2.2–6.5 m height pathwayThe football guide scales height and setback for small/medium and larger venues.
16Calibration
Court / field corner markingBasketball calibration aligns the centreline and four court corners; football calibration aligns the centreline, four field corners and field type.
17Live-stream modes
1 panorama or left/right camera streamsOne panoramic live stream can run per device. Left/right camera streams can run simultaneously using different RTMP addresses.
18Video management
Record, play, download + deleteRecorded videos are stored on the device SD card; highlight videos can be viewed and downloaded through the app.
19Scoring
Basketball + football scorekeeperDuring live or recorded operation, match stage and scores can be displayed in the preview and live platform with editable match and team information.
20Environmental
IP54Operating range documented at -10°C to +50°C.
21Camera body
198 × 210 × 66 mmApprox. 1.4 kg.
Use the sport-specific setup table rather than one universal mounting height. Final placement should be tested for full playing-area visibility, safe stable mounting, power and network requirements before normal use. Product imagery on this page shows the current VAKTAR brand direction; supplied camera hardware itself is not externally branded.
Sports-vision pathways
One VAKTAR platform, different operating goals for clubs, schools and public venues.
Define the intended outcome before mounting and network decisions are frozen. Livestreaming, coaching review, highlights, event capture and repeatable multi-venue deployment can place different demands on the same core system.
Sports clubs
Club livestreaming, highlights and coaching review
Use VAKTAR for match recording, selected live streams, coaching review and repeatable club content without planning every fixture around a conventional camera crew.
Explore pathway
Schools + education
School sport recording and coaching review
Schools can plan a controlled capture pathway for fixtures, training and coaching where power, network, privacy and operating responsibility are defined by the school.
Explore pathway
Councils + public facilities
Technology-ready community sports venues
Public facilities can incorporate camera mounting, power and data into wider court projects where the operator has a clear policy for recording, access and event use.
Explore pathwayResorts + destination sport
Capture tournaments, camps and guest recreation
Destination venues can consider VAKTAR alongside courts and sports amenities for organised events, coaching camps and venue content where the operating model justifies it.
Explore pathwayInternational projects
Repeatable multi-site sports capture
For international programmes, document mounting, calibration, power, network and operator setup so each venue can be commissioned against the same reference process.
Explore pathwayOne system · multiple sports
Capture. Track. Analyse.
VAKTAR is positioned as a multi-sport vision platform. The same camera pathway can be planned around different court and field environments, with final placement, calibration, power and network matched to the sport and venue.
VAKTAR in context
Hardware, multi-sport use and real-time insight.
The camera hardware is intentionally shown without exterior branding. VAKTAR is the customer-facing platform identity around the sports-vision system, its project pathway and supporting website experience.
Project fit
From venue setup to post-match video in one sports-vision workflow.
180° panoramic capture
The dual-lens view combines left and right camera footage into a broad fixed-position panorama.
Sport-specific calibration
Basketball and football workflows use centreline and corner marking so the app understands the playing area before capture begins.
Live + recorded workflows
Live streaming can use wired, Wi-Fi or 4G connectivity while local recording can continue without external network access.
RTMP flexibility
The current manual supports a panoramic live stream or simultaneous left/right streams using different RTMP addresses, depending on the selected workflow.
Highlight capture
Highlight capture is documented for key moments such as goals, with highlight videos available for later viewing and download.
Match scoring
Basketball and football scorekeeper pages can add match stage and scoring information to the preview/live platform during recording or streaming.
Video management
Recorded footage can be played, downloaded or deleted through Recording Management, while remaining time and storage can be checked in device information.
Clear operating indicators
Front operation lights identify power, recording, live streaming, upload and firmware-update states; battery lights show charge level.
Repeatable setup
The simplified setup flow is mount, power, connect, network, preview, calibrate, select sport, mark the venue and then record or stream.
Club media + coaching pathway
For clubs, VAKTAR can support coaching review, highlights, selected livestreams and a more repeatable content workflow, subject to the club’s own privacy and operating policies.
School + public-venue planning
Schools and public operators should define who controls the camera, how footage is used, network access, privacy requirements and safe mounting before the system becomes part of normal venue operation.
Common applications
BasketballFootball / soccerPickleballRugbyIce hockeyFrisbeeSchoolsClubsTraining venuesTournamentsCommunity sportEvents
Product status
What Apollo has confirmed at catalogue level.
Apollo's catalogue owner, project-brief pathway and core product record are complete enough to progress into project review and manual quotation. This is not a statement of engineering approval or destination compliance.
2 controlled current/reference technical documents are registered to this product pathway.
Apollo has an explicit regional priority map for this product. Regional mapping supports discovery and project review; it is not blanket compliance certification.
Status signals describe Apollo's current product record and project pathway. They do not replace project-specific engineering, testing, local approvals or destination compliance review.
